Wall Pad Impact Fire Rated 2 Inch x 2x5 Ft. WB LipTB
Be the first to review this product
$284.00/each
$28.40/sqft
Handling Time Estimate: 6-8 Weeks
- ASTM Class A fire-rated construction
- ASTM F2440-18 impact attenuation tested
- Leather grain emboss texture
- See More Details
- ASTM Class A fire-rated construction
- ASTM F2440-18 impact attenuation tested
- Leather grain emboss texture
- Extra-firm polychloroprene latex compound foam core
- BACshield for antibacterial and antifungal protection
- Available in various bright and bold colors
- 14 oz vinyl laminated polyester covering
- Nailing margin for permanent direct wall installation
- Gym Wall Pads
- Basketball Court Wall Pads
- Fitness Facilities
- Sensory Rooms
NOTE: This item is a custom order and is not returnable.
The Wall Pad Impact Fire Rated 2 Inch x 2x5 Ft. WB LipTB product is engineered to provide both impact protection and Class A fire safety standards for facilities where safety is a priority and fire rated pads are required or wanted. This wall padding system meets the requirements of ASTM E-84 Class 'A' Fire Rating and ASTM F2440-18 Impact Attenuation Standards.
Using an extra-firm polychloroprene latex compound foam core, the wall panel achieves impact attenuation ratings of less than 1000 HIC and less than 200 G-max, providing effective protection against impact-related injuries.
The panel consists of a foam filler laminated to a recycled composite wood backing and fully enclosed in a Class A flame-retardant vinyl laminated polyester covering. The covering wraps the face, sides, ends, and all wood edges, and is securely stapled to the rear of the backer board.
Designed to be installed permanently with screws, with a wood lip at the top and bottom of the wall pad.Using an extra-firm polychloroprene latex compound foam core, the wall panel achieves impact attenuation ratings of less than 1000 HIC and less than 200 G-max, providing effective protection against impact-related injuries.
The panel consists of a foam filler laminated to a recycled composite wood backing and fully enclosed in a Class A flame-retardant vinyl laminated polyester covering. The covering wraps the face, sides, ends, and all wood edges, and is securely stapled to the rear of the backer board.
Features of Wall Pad Impact Fired Rated
- Backer Board: 7/16-inch (11 mm) SFI® Certified Responsible Forestry recycled composite wood backer board that is urea formaldehyde-free. Contributes toward satisfying LEED® Credit IEQ 4.4 requirements
- Foam Core: 2-inch thick low-smoke polychloroprene compound foam with a density of 9 lb/ft³. Achieves ASTM E-84 Class A fire rating with a Flame Spread Index of 25 or less and a Smoke Developed Index of 450 or less. Meets ASTM F2440-18 impact attenuation requirements.
- Vinyl Covering: 14 oz. vinyl laminated polyester that is puncture-resistant and tear-resistant. Features a leather texture. CPSC CPSIA 6P compliant with phthalates less than 0.1% and lead less than 100 ppm. Meets NFPA 701, CSFM, and ASTM E84 Class A fire requirements with Flame Spread Index of 25 or less and Smoke Developed Index of 450 or less. UV treated for long-term appearance retention. BAC Shield treated to provide: Antibacterial, antimicrobial, antifungal, and anti-mildew protection
Customized Wall Pads
Wall pads can be ordered in custom sizes to fit your gymnasium, studio, or other installations. We can also do custom graphics and logos reflecting your business, school, or sports team’s branding. Please call for a quote for custom orders.
Please note that one Greatmats logo will be applied to one wall mat per project.
Maintenance
Clean with hot water using a sponge. Do not soak in water.
Shipping
Ships via freight delivery shrink wrapped on pallets.
Please review our shipping disclaimer.
| SKU# | GM110-900-2x5-tb |
| In Stock | Yes |
| Product Type | Mat |
| Material Type | Vinyl covered Foam |
| Product Edging | Straight |
| Thickness | 2 inch |
| Width | 2.00 feet |
| Length | 5.00 feet |
| SF per Item | 10.00 |
| Weight | 40.00 lbs |
| Packaging | Shrink Wrapped on Pallets |
| Non Absorbent | No |
| Special Adhesives | No |
| Interlock Loss | 0.00 feet |
| Interlocking Connections | No |
| Made In | USA |
| Surface Finish | Smooth flat |
| Surface Design | Solid color |
| Installation Method | Direct screw to wall |
| UV Treated | Yes |
| Reversible | No |
| Border Strips Included | No |
| Indoor or Outdoor | Indoor |
| Manufacturer Warranty | 1 year limited |
View Installation InstructionsRECENTLY VIEWED
