SKU# GeoGridStnd

GeoGrid Cellular Paving System

GeoGrid Cellular Paving System full. GeoGrid Cellular Paving System corner close. GeoGrid Cellular Paving System interlock. GeoGrid Cellular Paving System interlock connected. GeoGrid Cellular Paving System full angled. GeoGrid Cellular Paving System thick. GeoGrid Cellular Paving System bottom close. GeoGrid Cellular Paving System close. GeoGrid Cellular Paving System close top.

Be the First to Write a Review
$5.69 per Tile - $2.16 per SF On Sale - Reg: $7.12 per Tile - In Stock
Ships out 7-10 Days
Ship times are typical, inquire for immediate availability.
Color:
4 Tile Minimum


Try the Pro Floor Designer

Create complex room layouts to scale.

Request a Sales Person Contact
DESCRIPTION⌃ Back to top
  • Benefits
  • Capable of withstanding up to 35 tons per sq ft
  • Provides ground reinforcement and stabilization
  • Lightweight and easy to install interlocking design
  • Patented design allows for expansion and contraction
  • Cellular design allows for dispersion of excess rain or flood water
  • Comes in pre-connected 4 grid sections, 60 sections per pallet
  • Manufactured from 100% recycled or virgin HDPE
  • Grids can be filled with decorative stones or seeded with grass
Use Types

Driveways, Flood prone areas, Parking lots, Pathways, Outdoor event areas


The enables the fast and efficient implementation of ground reinforcement and stabilization. The cellular design of the grids allows the dispersion of excess rain or flood water which makes it ideal for areas with water drainage problems.


GeoGrid is manufactured in the Europe from 100% recycled premium high density polyethylene and features an effective and simple interlocking design for fast and efficient installation. The grids can be lifted directly from the pallet as pre-connected 11 square foot sections, saving time and money. Each tile measures 19.5 x 19.5 inches x 4 cm.

GeoGrid van be in-filled with either aggregate or decorative stones to provide robust ground reinforcement for areas of high pedestrian or vehicle use and can also be seeded with grass to provide an environmentally friendly and aesthetic solution.

GeoGrid is ideal for new or overflow car parking, access routes, gateway or entrance areas, equestrian areas, fire and emergency routes, private driveways or golf buggy routes. With the option of white or high visibility demarcation blocks, GeoGrid is ideal for use in car parks, storage areas, road widening and fire and emergency lanes where there is a requirement for indicating specific zones such as disabled parking areas and traffic flow directions.

GeoGrid ground reinforcement and stabilization grids can equal or better the axle or point load performance of other currently available 1.6 or 2 inch cellular geopavers. GeoGrid Standard can withstand loads up to 350 tons per square meter.

Shipping

Ships on pallets via freight delivery.

This Product Ships Freight Only.
Please review our shipping disclaimer.


NOTE: This item is a custom order and is not returnable.

SPECIFICATIONS⌃ Back to top
In Stock Yes
Product Type Tile
Material Type Polyethylene Plastic
Product Edging Interlocking
Thickness 4 cm
Width 1.62 feet
Length 1.62 feet
SF per Item 2.64
Weight 2.40 lbs
Packaging Shrink Wrapped on Pallets
Number of Pieces per Package Type 240
Non Absorbent Yes
Special Adhesives No
Universal Interlock No
Interlock Loss 0.00 feet
Interlocking Connections Yes
Made In Europe
Order Minimum 4
Surface Finish Open cell grid
Surface Design Solid color
Installation Method Interlocking, dry lay
UV Treated No
Reversible No
Border Strips Included No
Manufacturer Warranty 1 year limited
PDF DOCUMENTS⌃ Back to top

down arrow4 View Specifications Data Sheet


You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Q & A⌃ Back to top
Ask a question about this product

Product Questions:

what is the base used to install? material and depth?
A compacted surface is preferable, however a non-disturb earth can work as well.
